Product Summary

The MB90F497GPFM-G is a general-purpose, high-performance 16-bit microcontroller. It was designed for devices like consumer electronics, which require high-speed, real-time process control. This device features an on-chip full-CAN interface. The MB90F497GPFM-G peripheral resources include on chip 8/10-bit A/D converter, UART (SCI) 0/1, 8/16-bit PPG timer, 16-bit I/O timer (16-bit free-run timer, input capture 0, 1, 2, 3 (ICU) ) , and CAN controller.

Parametrics

Absolute maximum ratings: (1)Power supply voltage: VCC: VSS - 0.3 to VSS + 6.0 V; AVCC: VSS - 0.3 to VSS + 6.0 V at VCC = AVCC; AVR: VSS - 0.3 to VSS + 6.0 V at AVCC ≥ AVR; (2)Input voltage, VI: VSS - 0.3 to VSS + 6.0 V ; (3)Output voltage, VO: VSS - 0.3 to VSS + 6.0 V ; (4)Maximum clamp current, ICLAMP: - 2.0 to + 2.0 mA ; (5)Total maximum clamp current, ICLAMP:20 mA max; (6)L level maximum output current, IOL: 15 mA max; (7)L level average output current, IOLAV: 4 mA max; (8)L level maximum total output current, SIOL:100 mA max; (9)L level average total output current, SIOLAV: 50 mA max; (10)H level maximum output current, IOH: -15 mA max; (11)H level average output current, IOHAV:-4 mA max; (12)H level maximum total output current, SIOH: -100 mA max; (13)H level average total output current, SIOHAV: -50 mA max; (14)Power consumption, PD: 315 mW max; (15)Operating temperature, TA: -40 to +105 ℃; -40 to +125 ℃; (16)Storage temperature, Tstg: -55 to +150 ℃.

Features

Features: (1)Models that support +125 ℃; (2)Clock; (3)Built-in PLL clock multiplier circuit; (4)Choose 1/2 oscillation clock or ×1 to ×4 multiplied oscillation clock (for a 4-MHz oscillation clock, 4 to 16 MHz)machine (PLL) clock.

Diagrams
